VLX 100 Pivot Door

VLX 100 Pivot Door in Jupiter, FL | Sightline Windows & Doors Jupiter

The VLX 100 Pivot Door is a heavy-duty aluminum entry system that rotates on a vertical center axis, built for homeowners and architects who want oversized glass and a true architectural statement. At Sightline Windows & Doors Jupiter, we’re an authorized ViewLux installation partner, which means every door we sell carries full factory warranty protection and is installed to the manufacturer’s exact specifications. In Jupiter, where modern coastal homes along the Intracoastal and contemporary builds in Abacoa are raising the bar for curb appeal, the VLX 100 has become the door people notice before they even step inside. If you’re pricing a pivot door for new construction or a dramatic replacement in Jupiter, call us at (772) 362-5402 for a free on-site measurement and written estimate.

Call (772) 362-5402

Product Overview - VLX 100 Pivot Door

The VLX 100 is built around a simple idea: your front door should move differently than every other door on the block. Instead of hanging from side-mounted hinges, this system rotates on a precision-engineered vertical axis set into the floor and head jamb. The result is a sweeping, almost theatrical motion that handles panels up to 60 inches wide and 120 inches tall without the visual interruption of a traditional hinge barrel.

We install the VLX 100 for clients across Jupiter who are after that gallery-museum quality in a residential setting. The heavy-duty aluminum frame is extruded to a 2.56-inch profile width with a 0.098-inch wall thickness, giving it the structural backbone to carry massive glass lites without flexing or racking over time. The aluminum is thermally broken, which matters more than most people realize until they feel the difference in summer heat transfer.

What draws Jupiter homeowners to this series isn’t just the scale. It’s the restraint of the design. Slim sightlines, minimal hardware visibility, and a floor plate that sits nearly flush with finished flooring. Whether you’re opening onto a courtyard in Admiral’s Cove or framing sunset views over the Loxahatchee River, the door becomes a moving wall of glass rather than an obstacle between spaces.

Technical Specifications

Before

After

Performance Features

Thermal Efficiency

The VLX 100 uses a full thermal break to separate interior and exterior aluminum surfaces, cutting conductive heat transfer significantly. NFRC-rated performance means the numbers are verified by independent testing, not claimed by marketing. In Jupiter’s climate, where August afternoons routinely push 90°F with punishing humidity, that thermal break keeps conditioned air inside and radiant heat outside where it belongs.

Acoustic Performance

Large glass panels can turn into amplifiers for street noise, aircraft from Palm Beach International, or boat traffic on the waterway. The VLX 100’s frame engineering and laminated glass option work together to dampen sound transmission. Laminated glass in particular adds a polyvinyl butyral interlayer that absorbs vibration frequencies where standard monolithic glass would simply transmit them.

Airtightness & Weather Seal

We seal every perimeter joint with AAMA 812-specified low-expansion foam sealant during installation. The door’s own gasket system compresses against the frame under latch pressure, creating a continuous air barrier. In Jupiter’s pollen-heavy spring months and during Saharan dust events, that seal keeps your interior air filtered and your HVAC system from fighting uncontrolled infiltration.

Waterproofing

The threshold system is designed with positive drainage and a sloped sill profile that sheds wind-driven rain rather than pooling it. Our AAMA 2400/2410-compliant installation includes pan flashing integration at the rough opening, directing any incidental water back outside. For Jupiter homes exposed to direct onshore flow, this is not a theoretical benefit.

Wind Resistance

The VLX 100 is wind-load rated for local climate requirements, with the heavy 0.098-inch wall thickness and reinforced corner construction providing torsional rigidity. The pivot hardware anchors into structural framing at both floor and header, distributing wind pressure across the opening rather than concentrating it at hinge-side fasteners. Impact-resistant laminated glass is available for homes in wind-borne debris regions.

Security & Hardware

Pivot doors carry unique security considerations because the locking points differ from hinged systems. The VLX 100 uses multi-point locking hardware that engages at the top, bottom, and deadbolt positions. The floor-mounted pivot pin is tamper-resistant from the exterior, and laminated glass adds forced-entry resistance since the interlayer holds shards in place even after impact.

Color & Glass Options

Six finishes give Jupiter homeowners real flexibility without overwhelming the decision. Premium Black and Anodized Silver dominate the contemporary builds we’re seeing in Jupiter Yacht Club and along Beach Road, where architects are specifying dark frames against white stucco or raw concrete. Pure White works for coastal traditional homes that want the pivot drama without contrasting against Bahamian shutters or pale siding. Bronze and Champagne split the difference, warm enough for Mediterranean-influenced architecture without reading as dated. Teak Wood is the outlier that surprises us with how often it gets specified for homes where interior wood ceilings or decking continue the material story through to the entry.

Glass selection depends on what the door needs to do. Clear is obvious for views. Frosted and Obscure give privacy for street-facing entries or bathrooms opening to courtyards. Low-E coating is standard recommendation for any Jupiter installation facing west or south. Tempered meets safety code for doors. Laminated does that plus adds impact resistance, sound damping, and UV filtration. We walk clients through the glass wall at our showroom so they see the difference in transmission and privacy level rather than guessing from sample chips.

Installation by Sightline Windows & Doors Jupiter in Jupiter

We’ve installed pivot doors in Jupiter long enough to know where the job goes wrong. It isn’t the door. It’s the opening preparation, the level of the sill, the square of the frame, and the sealant detail that nobody sees until five years later when water stains appear on the drywall.

Our process starts with a pre-installation inspection of the rough opening. We check for level, plumb, and square, and we don’t proceed until the framing is corrected. The VLX 100’s pivot hardware has zero tolerance for a twisted opening. The floor plate and head jamb pivot must align vertically within a sixteenth of an inch over a ten-foot height, or the door will bind, leak, or stress the hardware.

We install per AAMA 2400/2410 standards, which specify how the door interfaces with the weather barrier, how flashing layers integrate, and how we achieve structural attachment without compromising the thermal break. Every perimeter joint receives AAMA 812 low-expansion foam sealant to prevent air infiltration and provide a backer for the final sealant bead. We don’t use generic caulk from a hardware store. The foam and sealants we specify are tested as a system with the frame.

After setting, we operate the door through its full swing cycle, checking for even reveal gaps and smooth pivot action. We run a water test on the sill and jamb interfaces. We clean the glass and frame, protect the threshold with temporary covering, and walk the homeowner through operation and maintenance.

Here’s what matters for warranty: ViewLux’s factory coverage requires installation by an authorized partner using specified methods. Improper installation voids that protection. In Jupiter’s salt-air environment, where aluminum can corrode if dissimilar metals contact or drainage paths clog, that warranty isn’t paperwork. It’s your recourse if something fails. We document every installation with photos and compliance checklists so there’s no question of proper execution.

Jupiter’s building code requirements for wind-borne debris protection in certain zones also mean we coordinate impact-rated glass and installation documentation for permit closure. We pull permits when required, schedule inspections, and don’t consider the job complete until the certificate of completion is posted.

Frequently Asked Questions - VLX 100 Pivot Door

What is the lead time for the VLX 100 Pivot Door?

Lead time typically runs 8-12 weeks from signed approval and deposit, depending on glass selection and finish availability. Custom sizes and impact-rated laminated glass can extend that slightly. Call (772) 362-5402 to check current production schedules for your specific configuration.

Does the VLX 100 qualify for energy tax credits?

The NFRC-rated thermal performance and Low-E glass options may contribute to whole-home energy efficiency improvements that qualify under federal or state programs, though the door itself is not independently eligible as a standalone product credit. We provide certified performance data for your tax preparer or energy rater. For current program details, call us at (772) 362-5402.

What warranty comes with the Pivot Door?

ViewLux provides a limited lifetime warranty on the aluminum frame and finish, with 10-year coverage on the sealed insulating glass unit and 5 years on hardware, contingent on authorized installation. Sightline Windows & Doors Jupiter backs our installation workmanship with our own service guarantee. For full warranty terms, request our written documentation during your estimate.

Can I customize the size?

The VLX 100 accommodates panels up to 60 inches wide and 120 inches tall within the standard program. Dimensions beyond that require engineering review and may involve structural modifications to the opening. We measure on-site, confirm feasibility, and provide factory pricing for any non-standard configuration. Call (772) 362-5402 to schedule a measurement.

How do I maintain aluminum frames in Jupiter’s coastal climate?

Rinse frames quarterly with fresh water to remove salt accumulation, wash annually with mild soap and a soft brush, and keep drainage channels clear of debris. Never use abrasive cleaners or steel wool on anodized or painted finishes. Inspect weatherstripping yearly for compression set. Proper maintenance prevents galvanic corrosion and preserves finish appearance for decades in Jupiter’s salt-air environment. We provide a written maintenance guide at installation.

Get a Quote - VLX 100 Pivot Door in Jupiter

The VLX 100 Pivot Door isn’t an impulse purchase. It’s a decision that changes how your home feels every time you walk through it. At Sightline Windows & Doors Jupiter, we’ll measure your opening, confirm structural feasibility, and deliver a written line-item quote with no obligation. Every estimate includes finish samples, glass transmission demonstrations, and a clear timeline from deposit to installation. Ready to see what a pivot door does for your Jupiter home? Call (772) 362-5402 or stop by our showroom. We’ll walk you through a working display and start your project when you’re ready.

Written by the team at Sightline Windows & Doors Jupiter, serving Jupiter since 2008.
